[Word] to introduce myself I was a block Raspberry Pi A + / B + / 2 adapter generation B turn Ard uino board with a variety of important resources.   [What I mainly do? ] Ard uino is a huge ecosystem, if Pi interface can be converted to a standard Ard uino, it will be able to access a variety of Ard uino expansion board, access Ard uino ecosystem, more available resources. I have more do.   [I] BASIC   Compatible with Ard uino UNO, Leonardo, easy access to a variety of Ard uino expansion board XBee-board interface for easy access to a variety of XBee modules Onboard USB TO UART, serial facilitate debugging, can also be configured as XBee USB Adapter Onboard sensor interface, easy access to a variety of sensors Onboard ADC, 10 bit, 38KSPS, 11 channels (6 channels for Ard uino interface, 5 channel for accessing sensor) Onboard RTC, which is one of the most commonly used functions

1. Ard uino connector : for connecting Ard uino shields
2. ICSP interface : Ard uino ICSP
3. XBee connector : for connecting XBee communication modules
4. Sensor interface : for connecting sensors
5. Raspberry Pi connector : for connecting Raspberry Pi
6. USB TO UART
7. TLC1543 : AD converter
8. PCF8563 : RTC
9. CP2102
10. 32.768KHz crystal : for RTC
11. Power indicator
12. XBee state LED
13. XBee and Ard uino interface RESET button
14. XBee EASYLINK button
15. RTC battery holder : for CR1220 button battery
16. TLC1543 reference voltage configuration jumper
17. RTC jumper
18. UART jumper

    • when connecting P_RX and CP_TX, P_TX and CP_RX respectively, USB TO UART is connected to Raspberry Pi serial port
    • when connecting XB_RX and CP_TX, XB_TX and CP_RX respectively, USB TO UART is connected to XBee serial port
    • when connecting XB_RX and P_TX, XB_TX and P_RX respectively, Raspberry Pi serial port is connected to XBee serial port
19. Ard uino AD selection jumper

    • short 2 and 3 : Ard uino A0-A5 as AD input
    • short 1 and 2 : Ard uino A0-A5 as digital control
20. Ard uino I2C selection jumper

    • short the jumper : Ard uino A4-A5 as I2C control (the A4-A5 of Ard uino AD selection jumper should be opened)
21. Ard uino SPI selection jumper

    • short 1 and 2 : Ard uino D11-D13 as SPI control (default)
    • short 2 and 3 : Ard uino D11-D13 as digital control
