USB Data acquisition card V5.1 (previous V5.0) is with 8 channels single-ended 16bit High-precision synchronous analog signal acquisition ( the highest stable sampling rate  48KSPS,48X8K Characters per second ) ,2 channel 12Bit analog outputs ,8 channel Digital signal isolation input/ 8 channel digital signal isolation ,1 channel PWM Input, 1channel counter and 2 channel PWM Output.

Mainly for high- precision analog acquisition ,Synchronous acquisition , interference resistance, each module isolation and other industrial occasions , particularly suitable for use in the field of power electronics.

1. Features:

1. 8 Road 16Bit synchronous acquisition.   only 1mV error In -10V -+ 10V Input gain range; ;
2. Input impedance greater than 1M Ohm , the signal can directly access for most measurements , do not need to pre- impedance conversion circuit , input channel-16-16VClamp protection , while providing7KVOfESDProtection ;
3. Onboard flexible digital first order sinc Filter , may be provided by a flexible digital filtering different oversampling ratio at low sampling rate , the decrease in the signal noise;
4. USB Isolation communication , capture cards and computer use of isolationUSBNo electrical connection between the communication , capture card and a computer , there is no common ground issues that can withstand between the capture card and a computer5KVInstantaneous voltage , even if the external high voltage burn capture card also ensures security of the computer ;
5. Digital IO Opto-isolated inputs and outputs are used , such as to avoid interference relay system to capture card , but also play a role in security isolation .
6. work in linux, Win2000 / XP / WIN7 other popular operating systems , and provides DLL for VB.net, dynamic link library VC, C ++ Builder, Dephi, LabVIEW, Matlab, QT and other common programming language, programming functions interface is simple to use, easy to write applications.

2. performance indicators

USB Bus Performance

• USB2.0 High-speed bus transfer
• Onboard 1kB Cache
• 5KV Isolated communications

Analog signal input

• analog input channels :      8 Single-ended ( synchronous acquisition )
• voltage inputs : -16--16V
• input signal range : -10--10V ( PGA = 1 ) , -5V - 5V ( PGA = 2 )
• Analog Input impedance: < 1M
• Resolution : 16Bit (65535)
• The maximum total error : < 0.05%
•  Programmable Gain : 1 , 2
•  sampling clock : 100sps-48Ksps Internal Clock

Analog signal output

• analog output channels : 2 Single-ended
• Analog output range : 0-5V
• analog output current : <10 mA
• Resolution : 12Bit (4096)
• Non-linear error :       ± 2LSB
• Scan Clock : 1sps-1000Ksps Internal Clock

Digital signal input/output

• Input / Output channels:    8in / 8out
• Input / Output mode:    Full input / Full output
• Input level :        Isolated input 3.3-50V
• Output Level :       Optically isolated open collector output

PWM Measuring input

• Number : 1
• Input voltage: 0-3.3V
• Input frequency: 1-200KHz
• Input Duty Cycle : 1% - 99%
• frequency and duty cycle measurement error: 1%

Counter

• Counter Number : 1
• Input level : TTL ( 5V ) Or CMOS (3.3V)
• Count bits : 32 Bit ( maximum 65535 * 65535 )

PWM Output

• PWM Output channels: 2
• PWM Output level : CMOS
• Input Duty Cycle : 1% - 99%
• Output frequency: 1 - 1MHz
