Owon OW18B Digital Multimeter DC/AC Voltage Current Meter Handheld Voltmeter Ammeter Diode NCV Tester Multitester True RMS | Инструменты

---

1.Multifunctional, can measure AC/DC voltage, AC/DC current, resistance,  diode, capacitance,frequency, duty ratio,temperature,continuity,NCV. 2.Bluetooth function:can connect with Android,iOS device and computer. 3.Easy to read: 5999 counts backlight LCD with data hold function. 4.Accurate and reliable:relative measurement,True RMS. 5.More advantages:diode test,NCV test,low power indication,over-load protection,auto power off.

1.With non contact voltage test. 2.Multifunctional,can measure AC/DC voltage, AC/DC current, resistance,  diode, capacitance,frequency, duty ratio,temperature,continuity,NCV. 3.It's a perfect tool for the laboratory, factory and home.

Brand:OWON Model: OW18B Color: blue&gray Display:5999 counts Sample rate:3 times/second Battery: 9V battery(not included) DC voltage range: 60mV/600mV/6V/60V/600V/1000V DC voltage accuracy: ±(0.5%+2)/±(0.8%+2) AC voltage range: 600mV/6V/60V/600V/750V AC voltage accuracy: ±(0.8%+3)/±(1%+3) DC current: 600uA/6000uA/60mA/600mA/20A DC current accuracy: ±(0.8%+2)/±(1.2%+3) AC current: 600uA/6000uA/60mA/600mA/20A AC current accuracy: ±(1%+3)/±(1.5%+3) Resistance: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ Resistance accuracy: ±(0.8%+2)/±(2%+3) Frequency range:9.999Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/999.9KHz/9.999MHz Frequency accuracy: ±(0.8%+2) Capacitance range: 60nF/600nF/6μF/60μF/600μF/6mF/60mF  Capacitance accuracy: ±(3%+5)/±(5%+5) Duty ratio range:0.1%-99% Duty ratio accuracy: ±(1.2%+3)/±(2.5%+3) Temperature Range: -50~400°/-4058~752°   Temperature accuracy: ±(2.5%+3)/±(4.5%+15) Input impedance:10MΩ Auto range:yes Bluetooth:yes NCV test:yes Diode test:yes Continuity test:yes True RMS:yes Auto range:yes Data hold:yes LCD backlight:yes Relative measurement:yes Low voltage display: yes Auto power off:yes Input protection:yes Size: 190 x 85 x 50mm Weight: 328g

Package size: 210 x 132 x 55mm/8.27 x 5.2 x 2.17in Package weight: 531g/1.17lb General Box Package   1 x Digital Multimeter 1 x Pair of test leads 2 x Alligator Clip 1 x Thermocouple 1 x User Manual
