CNC Metal Printer Laser Marking Machine with 2D Worktable Gold Silver Cutting fiber laser marking machine for metal cnc

1. Compact: The high-tech product, which is combined of laser device, computer, auto controller and precision machinery.

2. High Precision: Re-position precision is 0.001 mm

3. High Speed: Imported scanning system makes the scanning speed is up to 7 m/s

4. Easily Operating:Afford the specific marking software based on Windows, which is real-time adjust the laser power and    pulse frequency. You can input and output by computer according to edit in the both of the specific marking software and the  graphic software such as AutoCAD, CorelDRAW and Photoshop.

5. Long life time: This machine have long life time that can over 100,000 hours

6. Energy Saving: The efficiency of optic-electrical converting is up to 30%

7. Low Running Cost: No wearing part. Free maintaining.

Model                                         MT-FP30B

Laser power                               30W

Working  Area                            110*110mm(150*150mm/200*200 mm optional)

Cooling Mode                             Air Cooling

Laser Wavelength                      10.64 um

Frequency of pulse                     20-100 KHz

Marking Depth                            ≤0.3 mm

Marking Speed                           ≤7000 mm/s

Marking Lines                              1-10 lines

Minimum Line Width                    0.01 mm

Minimum Character                     0.15 mm

Repeatability Accuracy                ±0.002 mm

Resolution Ratio                          0.1 mm

Marking Content                          Text, pattern, date, bar code, etc

Operation System                        Microsoft Windows XP or Windows 2000

Control Software                          EZCAD Control Software

Graphic Format Supported          BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc.

Unit Power                                   ≤0.8 KW

Operation Temperature                5°C-40°C

Relative Moisture                         ≤ 90%, no fog

Dimensions(L*W*H)                     75 x 47 x 81 cm

Power supply requirements         220V±10%/50HZ

Optional                                       Rotary device/2D/3D work table/110V voltage

Warranty                                      24 months

PRODUCT DETAIL

ACCESSORIES

1. Flash driver / u disk

2. Ruler

3. Ground wire

4. Power cable

5. Foot Pader / switch

6. key switch / laser switch

7. Scanner power switch

8. Emergency switch

9. Laser Power Adjust

10. Hexagon wrench

1.Standard plywood case, its compressive strength and bearing quality is better.

2.The board area is bit, the soil structure is good, it is better in leakproofness and waterproof.

3.When importing, the plywood case is with fumigation-free, the procedure is simple.

  MT-F20A packing size: 84*75*127 CM, GW: 65KG, NW:45KG.

Before the order:

1. We offer Sample free marking testing;

2. We offer Technical support for free;

3. We offer marking solutions for free.

After the order:

1. Machine user manual in English. (If you need, we also offer user manual in different languages;

2. Technical support for whole lifetime;

3. Marking solutions for whole lifetime;

4. 2 years warranty.

1.If you choose seller shipping method, please email us your port name to double check if it can be reached and delivery time. Please reconfirm the shipment information: consignee/contact person, detailed address, telephone number.

For Russia and Ukraine, we can ship machine to your city by land transportation. Please contact us to confirm the shipping cost and customs tax.

2. When payment and shipping information are confirmed, shipping will be made within 7 working days.

3. It's CIF trade term (insurance included). The buyer should pay surcharge of port, including handling charges, custom clearance cost and import taxes. EXW and FOB terms are also acceptable. We ship goods by sea to your seaport (you need to find broker to help you clear customs).

4. On arriving at the destination port, the machine should be picked up soon. Or the buyer should pay the relevant demurrage charges.

5. If want other courier like DHL, TNT, UPS, FedEx or EMS, please also provide us with your city name and post code, so we can check the delivery detail and cost.

6. Please check all goods carefully and report to us within one week if there are any parts loss or machine problems (photo evidence needed). The machine is specially customized product with big size, so we do not accept return with pretty high return cost. But we are confident in our products quality. And lifetime tech support and free spare parts (Consumable parts not included) during warranty will be offered for each buyer.

7. If we are not on line, please leave us messages on Aliexpress about any questions on our product or your order, then we will reply you within 24 hours.

Your feedback is really important to us, please take a few seconds to leave great feedback if you are satisfied withh our product or service, so many thanks!

If our goods or service does not satisfy you, or any questions, please contact us and give us a chance to improve before open a dispute or leaving any type of feedback.
