​2000W New Technology MPPT Gird Tie Wind Inverter with LED Display for Wind Turbine with Limiter AC 48V for 110v/220V Auto

1000W Grid Tie Inverter converts DC power produced by Solar Panels to AC, connects to the grid and feed all of the power available from the panels to the AC load. Smart Micro inverter is synchronized and in-phase with the utility grid. If the Solar Panel is producing less power and the GTI cannot deliver all the power needed by the load, then power will be supplemented by the Grid.

1.Creative MPPT tech makes efficiency higher than 99%. Reaction more sensitive and MPPT locking faster；

2.Parallel modular components design (stacking use) is convenient for systems setting, flexible combination and system scalability；

3.All-round protection functions: overcharge protection, over discharge protection, overload protection, electronic short circuit protection and reverse connection protection；

4.Anti-circle island protection.

​

Inverter LCD Display :

​

The Inverter display can show many information,The main interface of the display and the icons explainations are show above.

1.Set Menu:Choose the set menu icon on the main screen interface,click the confirm button to enter into the interface show below,In this interface,can set the LCD backlight always on or auto turn off backlight after 3 minutes no action.

The inverter also integrate with internal limiter and external limiter function which can prevent excess power from going to the public grid.Select the internal limiter mode,inverter will work under limiter mode,output power of the inverter will be determined by load power.Select the external limiter mode,inverter need a external limiter module working with it.For more  details about the limiter function,pls contact supplier.

4.Power View: In this interface,the display shows real time power,PV input voltage, inside temperature,date and time.

Clock And Date Setting: Set the clock and date in this page,save the setting before exit.

AC Output current waveform and PF Test Of 2000W Model

Tested 2000W model at nearly full load,Output current waveform shows good pure sine wave in oscilloscope,PF value also shows in good result,99.8% PF value.

Installing  Grid Tie Power System involves several key steps:

1. Considering the total capacity of the grid tie power system that you need.

2. Choosing applicable wind turbine for Grid Tie Inverter.

3. Selecting accessory for installation of the Grid Tie Power System .

4. Selecting correct model of  Grid Tie Inverter.

5. Installing wind turbine to suitable place.

6. Installing  Grid Tie Inverter to suitable place.

7. Connecting  Grid Tie Power System with cables and connectors.

8. Grounding the system.

Grid Tie Power System to Three Phases Utility Grid

Moreover, with a group of adept and experienced R&D staff, we are appreciated to provide top quality and excellent performance solar and wind inverter and related products for you. And we also can offer personalized services, tailor-made sevices for you.

Welcom to keep in touch with your any questions about our solar and wind products.
