Product Description

Product Application

Hot 3d crystal laser engraving machine price 4060 100w reci rubber stamp laser engraving machine

Color	Red and Black
Laser Tube	Sealed CO2 glass Tube
Working Table	Honeycomb (Aluminum optional)
Laser Power	100w reci
Cutting Speed	0-100 mm/s
Engraving Speed	0-600mm/s
Resolution	±0.05mm/1000DPI
Minimum Letter	English 1×1mm (Chinese Characters 2*2mm)
Support Fils	BMP,HPGL,PLT,DST and AI
Interface	USB2.0
Software	RD Works
Computer system	Windows XP/win7/ win8/win10
Motor	Stepper Motor
Power Voltage	AC 110 or 220V±10%,50-60Hz
Power cable	European Type/China Type/America Type/UK Type
Working Environment	0-45℃(temperature)      5-95%(humidity)
Power consumption	<900W (Total)
Z-Axis Movement	Automatic
Position system	Red-light pointer
Cooling way	Water cooling and protection system
Cutting thickness	Please consult sales
Packing Size	148*85*88cm
Gross Weight	135KG
Package	Standard plywood case for export
Warranty	All life free tech support, one year warranty, except consumables like laser tube, mirror and lens, etc.
Free accessories	Air Compressor/Water Pump/Air Pipe/Water Pipe/Software and Dongle/ English User Manual/USB Cable/Power Cable
Optional parts	Spare focus lens Spare reflecting mirror Spare rotary for cylinder materials Industrial Water cooler



Main Features

1. pass through front and back of machine , support long materials to be produced .

2. X, Y axis linear guide with higher precision and faster speed.

3. Provide 12 months laser tube warranty, global warranty (if the laser tube has quality problems during the warranty period, we will provide new laser tube free of charge and pay the courier fee)

4. Ruida system with color screen supports multiple languages Detailed Images

Machine Parts

Name: blade work table

Brand: JINZHIYIN

Original: China

Support dual platform, blade platform and honeycomb (optional one or two)

Main Features

Name: laser head
Brand: JINZHIYIN
Original: CHINA
Flying light path design, small optical path deviation, high stability easy adjustment

Machine Parts

Name: Y axis
Original: China
Double square linear guides

Main Features

Name: Laser tube
Brand: Reci brand or EFR Brand
Original:China
EFR Laser tube 60w/80w/100w optional ( glable warranty 12 months,6000 hour work life-span )

Reci brand laser tube optional ( 10000 hours work life-span ). 80w w1 / 100w w2 tube optional









pass through front and back of machine , support long materials to be produced



Accessories



1, water pump*1pcs

2, air pump*1pcs

3, air pipe*1pcs

4,Tool bag*1pcs ( including rule, usb cable, power cable ,CD, hose clamp )

5, Machiner supporter and wheel

Optional accessories ( not free of charge).

1. rolling rotary device $ 60 usd.

2. four wheel rotary device $ 150 usd.

3. chuck rotary device $ 150 usd.

4. cw 3000 water chiller $ 150 usd.

5. cw 5000 water chiller $ 260 usd. ( have cooling water function )

Sample show Our Service







  Packing & Delivery

Packaging
Size	148(L) * 85 (W) * 86 (D)
Weight	135kg
Packaging Details	NEW 4060 high speed laser engraving cutter machine 100W CO2 laser engraver with Ruida system for wood Mdf Glass STANDARD PLYWOOD CASE FOR EXPORT

Payment



shipment



Our Company

Jinan gold mark cnc machinery co.,ltd.

Jinan Laser Max Machinery Technology CO.,LTD is a high development factory,and professional export Company, based on China CCPIT and China Business Bureau support, we won lots of awards in exporting and Technological innovation. Our Company was founded in the year of 2012,has more than 100 employees, and factory area over 2000 square meters.
Our mainly produced products are CO2 Laser Engraver, Laser Cutting Machine and Fiber laser Marking Machine,covering the line of arts and crafts processing, advertising, signs, University education, medical industry, clothing processing, building models, wood furniture, plexiglass cutting, image carving and other industries.

As a Leader of China B2B, B2C, our products are sold out to America, Europe, Middle East and South Asia. We have many agent and warehouse in different Countries like Russia, Belarus, USA and Poland.Still looking for whole sellers, retailers and hobby users friends join us.

We have a young sales team, average age is 25 years old, we works day and night waiting for your inquires and questions. Let us cooperate together,to work out best solution for you to expand your business.



FAQ Q1. How to get the most suitable machine and best price
Please tell us the material you want to engrave or cut? Max size and thickness?

Q2. If we don't know how to use the machine,can you teach us?
Yes, we will, English manual and video will come along with the machine. You also can contact our service team if you need any help during use our machines.

Q3.How about your after-sales service?
we offer you 24 hours service by phone, Skype or Whatsapp.

Q4. Quality Control:
The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.

Q5. How we pay you?
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.And 100% quality check before shipping.
F.Send your order by air or by sea.
