AOB-131/ diffused silicon pressure transmitter /4-20mA constant water supply sensor / temperature | Автомобили и мотоциклы

AOB-131/ diffused silicon pressure transmitter /4-20mA constant water supply sensor / temperature | Автомобили и мотоциклы

  Main technical parameters of the product: Measurement range: -100KPa ~ 0-60MPa Maximum overload: 1.5 times of the standard range Pressure form: Pressure, differential pressure Precision grade: 0.25%F.S custom 0.5%F.S V Power supply voltage: 24VDC Load resistance: Less than or equal to 500. Measuring medium: Steam pressure or gas, liquid Long-term stability: + 0.2% F.S/ years Temperature drift: 0.03%FS/ C Compensating temperature: 0 to 80 Working temperature: -10 ~ 70 degrees C (the maximum can be 500 C / C) Structure characteristics: Shell: All stainless steel Measuring medium: Stainless steel non corrosive gas, liquid Pressure interface: M20 x 1.5 or user defined dead weight General 0.2kg, head of 0.6kg table Debugging method: Open the HSM connector, screw down the stainless steel tube, you can see the zero adjustment and full range resistor, external standard power supply and current meter (0.2), can be adjusted, the following steps are: The situation is not under pressure in the transmitter, zero adjusting resistor, the output current of 4mA; The transmitter is pressurized to the full scale, full range adjustment resistors, make the output current of 20mA; We repeated the above steps two or three times, until the normal signal; The adjustment is complete, tighten the cap. ] where the supply of products with instructions for use and certification, including product number, technical parameters, ex factory date, please carefully check, so as to avoid the wrong. We do not use hard objects directly extrude the transmitter diaphragm, so as not to damage the transmitter. The installation should be according to the product connection and thread type, check on site interface is consistent with the product interface, the connection should be slow to tighten, not the torque is applied directly to the transmitter housing, can only add on the interface pressure hexagonal. It is connected with the power supply should be strictly in accordance with the instructions of my company wiring connection. The transmitter overload pressure can not exceed 150% of range. The use of the abnormal, should turn off the power, stop using, check, or directly to my company technical department. The transportation and storage should restore the original packaging and store in a cool, dry and ventilated warehouse.
